Professional Structured Cabling Solutions

Certified Cat6 through Cat8, Fiber, and Wi-Fi wiring installations for offices, data centers, and industrial sites. Our BICSI-certified technicians deliver reliable, high-performance network infrastructure with 10Gb SFP+ technology.

Enterprise-Grade Ethernet Solutions (Cat6 to Cat8)

Future-proof your network infrastructure with our certified copper cabling installations designed for high-speed data transmission.

Cable Category Comparison

Specification Cat6 Cat6a Cat7 Cat8
Max Bandwidth 250 MHz 500 MHz 600 MHz 2000 MHz
Max Data Rate (up to) 10 Gbps 10 Gbps 10 Gbps 25/40 Gbps
Max Distance (10Gbps) 55m 100m 100m 30m
Shielding U/UTP or F/UTP F/UTP or S/FTP S/FTP S/FTP
Typical Use Cases Office networks, VoIP Data centers, 10G networks High EMI environments Data center interconnects

Cat8 Cabling: The Next Generation

Our Cat8 solutions provide the ultimate in copper-based network performance, ideal for data center environments and high-performance computing applications.

$350–$600 per drop

Includes full Cat8.2 installation with GG45 connectors and certification

Cat8 Advantages

  • 25Gbps/40Gbps speeds up to 30m
  • Backward compatible with RJ45 equipment
  • Ideal for spine-leaf data center architectures
  • Reduced latency for financial trading systems

Installation Requirements

  • Requires proper bend radius management
  • Specialized termination tools
  • Shielded pathways and grounding
  • TIA-568-C.2-1 compliant

Standard Ethernet Installations

$150–$300 per drop

Cat6/Cat6a installation with full certification

Performance Specifications

  • Up to 10 Gbps speeds (Cat6a up to 100m)
  • 550 MHz bandwidth (Cat6a: 750 MHz)
  • Reduced crosstalk with superior shielding

Installation Standards

  • TIA/EIA-568-C.2 compliant
  • Fluke DSX-8000 certification
  • Permanent link testing
  • Comprehensive documentation

Fiber Optic Cabling Solutions

High-performance fiber optic installations for demanding environments requiring maximum bandwidth and distance capabilities.

$3–$10 per foot

Price varies by fiber type (single-mode/multi-mode) and installation complexity

Fiber Options

  • Single-mode (OS2): Long-distance (up to 10km+)
  • Multi-mode (OM3/OM4): Short-distance high bandwidth
  • Armored fiber for harsh environments
  • Pre-terminated options available

Testing & Certification

  • OTDR (Optical Time Domain Reflectometer) testing
  • Insertion loss measurement
  • End-face inspection with probe cameras
  • Tier 1 and Tier 2 certification available

Common Use Cases

  • Building-to-building connections
  • Data center backbone infrastructure
  • High-bandwidth applications (4K video, medical imaging)
  • EMI-sensitive environments

Enterprise Wi-Fi & PoE Cabling

Complete wireless network infrastructure solutions with proper cabling for optimal coverage and performance.

$200–$500 per AP

Includes cabling, mounting, and basic configuration

System Components

  • Cat6 PoE+ cabling (802.3at compliant)
  • Professional-grade access points
  • Ceiling/wall mounts and cable management
  • Mesh networking capabilities

Site Survey Options

  • Predictive modeling for new construction
  • On-site active surveys with Ekahau
  • Heatmap reporting of coverage areas
  • Capacity planning for high-density areas

Installation Best Practices

  • Proper AP placement for optimal coverage
  • Channel planning to minimize interference
  • Power budget calculations for PoE devices
  • Future-proofing for Wi-Fi 6/6E standards

10Gb SFP+ Technology Solutions

High-density fiber connectivity using Small Form-factor Pluggable (SFP) technology for flexible, high-speed network architectures.

SFP+ Modules

SFP+ Technology Overview

SFP (Small Form-factor Pluggable) modules provide flexible, hot-swappable connectivity for network equipment, enabling seamless upgrades from 1G to 10G and beyond.

SFP+ Module Types

  • 10GBASE-SR: 850nm multimode (up to 300m)
  • 10GBASE-LR: 1310nm singlemode (up to 10km)
  • 10GBASE-ER: 1550nm singlemode (up to 40km)
  • 10GBASE-T: Copper RJ45 (up to 100m)

Deployment Benefits

  • Hot-swappable for zero downtime upgrades
  • Mix-and-match fiber types in same chassis
  • Lower power consumption than fixed ports
  • Future-proof with 25G/40G compatibility

Our Installation Services

  • SFP+ module installation and testing
  • Fiber patch panel organization
  • Transceiver compatibility verification
  • Link budget analysis

10Gb SFP+ vs Traditional Ethernet

Feature 10Gb Copper 10Gb SFP+ Fiber
Max Distance 100m (Cat6a) 300m (MM), 40km (SM)
Latency Higher Lower
EMI Susceptibility Yes No
Power Consumption Higher Lower
Best For Desktop connections Backbone, server connections

10Gb SFP+ Deployment Scenarios

  • Data Center: High-speed server-to-switch connections
  • Campus Networks: Building-to-building links
  • Storage: SAN/NAS connectivity
  • Video Production: High-bandwidth media transfer
BICSI Certified BICSI Certified BICSI Certified BICSI Certified

BICSI-Certified Installation Technicians

Our team holds advanced certifications in structured cabling installation, ensuring your network infrastructure meets industry standards and performs optimally.

We adhere to ANSI/TIA-568, ISO/IEC 11801, and NEC standards for all installations, with specialized training in Cat8 and 10Gb SFP+ technologies.

Complete Network Package

Save 20% when you bundle server setup with structured cabling

Starting at $4,500
  • Windows Domain Controller setup
  • 10 Ethernet drops (Cat6a, tested and certified)
  • Remote Access VPN configuration
  • Basic network switch configuration
  • Wireless access point (1 unit included)
  • Network documentation package
  • Optional: Upgrade to Cat8 or fiber connections
Get a Custom Quote

Ready to Design Your High-Performance Network?

Our cabling experts will design a solution tailored to your specific needs, whether you require Cat8 copper, fiber optic, or 10Gb SFP+ technology.

Schedule a Free Site Survey
